Triggered Fire when
Process Ignited Materials

Mishandling the Machine
and Caught On Fire

Don't Know How to
Safely Put Out Fire

Work with Toxic Fire
Extinguish Chemicals

Fire accidents triggered by lasers have been the concern of the whole industry. As one of the leading companies in the laser industry，xTool cares about all laser users' safety and is devoted to providing the safest solution. Thus, we have brought this “the world's first auto fire safety set for desktop Laser” to industry, to assure your safety and peace of mind while using laser machines.

Smart Fire
Detection & Alarm System

Auto Flame Detection

By using 5 fire detection sensors and integrated algorithms of light, temperature, and position inside the enclosed laser, xTool Fire Safety set is sensitive to any possible dangers of fire.

Auto Alarm Triggering

Immediately after it detects fire, xTool Fire Safety Set will automatically trigger the alarm, warning users of the fire by continuous "beeping" sounds. You can stop the alarm by pushing a button on it, if you want to deal with the fire in your own way.

Auto Power Cut

To prevent further exacerbating the burning fire and protect the laser machine from fire, the smart switch of the xTool Fire Safety Set will shut down the working laser automatically in a few seconds after the alarm sounds.

Auto Fire Extinguishing

After seconds of alarming, xTool Fire Safety Set will automatically release the CO2 gas into the enclosed laser and quench the fire with non-toxic and odorless fumes, preventing the laser machine from further damage and leaving a clean laser workspace afterwards.

*Noted that xTool Fire Safety Set cannot guarantee 100% safety in fire accidents. Please use the laser machine accordingto its guide and do not leave the machine during processing

Wide Range of Compatibility

Apply to all 455nm blue diode laser or CO2 laser machines that are in a 0.13m³ enclosed space.

Open Machine with an Enclosure

This product must be used in an enclosed space. For example, the xTool D1 series needs to be used with xTool Enclosure.As long as the enclosed space is under 0.13m³, xTool Fire Safety Set can extinguish the fire effectively.

Enclosed Machine

Enclosed machine that has the working space up to 0.13m3 can work with xTool Fire Safety Set. (Be aware that an air tube is needed to put into the enclosed space for it to work)

Part List

Control Box

Sensor hub

Sensor 1

Sensor 2 *4

CO2 gas bottle *4

Smart switch

Tube

Tube clamp

Cable tie pack

3M tape

Power adapter & cable

Cable clamp
