Extra Large Processing Area
The working area of 118''×18.5'', along with the S1 Conveyor Feeder, totally makes
batch engraving and cutting much easier.
*Maximum length requires additional purchase of 8 pairs of rails.
Extra Large Processing Area
Extra Large Processing Area The working area of 118''×18.5'', along with the S1 Conveyor Feeder, totally makes batch engraving and cutting much easier.
*Maximum length requires additional
purchase of 8 pairs of rails.
Automatic Conveying, Available in
Cutting and Engraving
Automatic engraving path planning and material conveying; Farewell to manual
material feeding and accuracy deviation.
Automatic Conveying, Available in Cutting and Engraving
Automatic engraving path planning and material conveying; Farewell to manual material feeding and accuracy deviation.
Easy Disassembly and Storage, Free Up Your Space
Easy Disassembly and Storage, Free Up Your Space
Metal Short Rail Design
Ensure safety while improving processing results.
Safety Materials: resistant to temperatures up to 600°C.
Cleaner Effects: breathable design of the processing area greatly reduces the burn marks.
Metal Short Rail Design
Ensure safety while improving processing results.
Safety Materials: resistant to temperatures up to 600°C.
Cleaner Effects: breathable design of the processing area greatly reduces the burn marks.
Unleash Your Creativity Everywhere
Creations Unrestrained by Materials
The material range is expanded from plywood, acrylic and fiberboard to
soft materials like felt, cork and EVA.
Unlock Your Creative Vision
Creations Unrestrained by Materials
The material range is expanded from plywood, acrylic and fiberboard to
soft materials like felt, cork and EVA.
Hard board
Soft and thick board
Make Your Use Easier
Pressing Wheels, High Stability
The upper and lower pressure wheels use anti-slip materials, and materials of various sizes can be easily fixed to prevent them from slipping or shifting during the conveying process.
Make Your Use Easier
Pressing Wheels, High Stability
The upper and lower pressure wheels use anti-slip materials, and materials of various sizes can be easily fixed to prevent them from slipping or shifting during the conveying process.
Buckle Design, Easier Assembly
With buckle design, the conveyor rail can be installed easily.
Buckle Design, Easier Assembly
With buckle design, the conveyor rail can be installed easily.
Color Markings for Pressure Setting
Different pressures need to be set for processing different materials. With color markings quickly matching each material pressure level, the pressure can be easily adjusted according to the material type.
Color Markings for Pressure Setting
Different pressures need to be set for processing different materials. With color markings quickly matching each material pressure level, the pressure can be easily adjusted according to the material type.
Knob for Easy Positioning Adjustment
Users can easily adjust the position of materials with the lower knob.
Knob for Easy Positioning Adjustment
Users can easily adjust the position of materials with the lower knob.
Aligning Grids, for Precise Process
Align the material with the grids on the conveyor feeder and convey the material to the device, so that the material is parallel to the conveying direction.
Aligning Grids, for Precise Process
Align the material with the grids on the conveyor feeder and convey the material to the device, so that the material is parallel to the conveying direction.
Specification
| Product Infomation | Automatic Conveyor Feeder for xTool S1 |
|---|---|
| Applicable to | xTool S1 |
| Package Size | 29.8''*10.7''*8.5'' (757*271×*216mm） |
| Product Size | 24.7''*7.9''*5.3'' (628*200*135mm) |
| Product Weight | 7.8kg |
| Max. speed | 160mm/s |
| Work Area | |
| Maximum Processing Area | 118''×18.5'' (3000*470mm) |
| Maximum Material Width | "21.5'' (545mm)" |
| Minimum Material Width | 2.5'' (65mm) |
| Maximum Material Thickness | 0.55'' (14mm) |
| Conveyor Rail | Support Hard Material Length (including hanging in the air 30cm) | Support Processing Length (including hanging in the air 30cm) |
|---|---|---|
| Basic (2 pairs)*1 | 39'' (1m) | 34'' (0.85m) |
| Basic (2 pairs)*1+add on kit (2 pairs)*1 | 64.5'' (1.64m) | 58.6'' (1.49m) |
| Basic (2 pairs)*1+add on kit (2 pairs)*2 | 90'' (2.3m) | 84.6'' (2.15m) |
| Basic (2 pairs)*1+add on kit (2 pairs)*3 | 118'' (3m) | 112.2'' (2.85m) |
Soft Material
Without Conveyor Rail, the material can be hung down on both sides of the working area of conveyor feeder.（Some soft materials need to be processed with PET tape）
Specification
| Product Infomation | Automatic Conveyor Feeder for xTool S1 |
|---|---|
| Applicable to | xTool S1 |
| Package Size | 29.8''*10.7''*8.5'' (757*271×*216mm） |
| Product Size | 24.7''*7.9''*5.3'' (628*200*135mm) |
| Product Weight | 7.8kg |
| Max. speed | 160mm/s |
| Work Area | |
| Maximum Processing Area | 118''×18.5'' (3000*470mm) |
| Maximum Material Width | "21.5'' (545mm)" |
| Minimum Material Width | 2.5'' (65mm) |
| Maximum Material Thickness | 0.55'' (14mm) |
| Conveyor Rail | Support Hard Material Length (including hanging in the air 30cm) | Support Processing Length (including hanging in the air 30cm) |
|---|---|---|
| Basic (2 pairs)*1 | 39'' (1m) | 34'' (0.85m) |
| Basic (2 pairs)*1+add on kit (2 pairs)*1 | 64.5'' (1.64m) | 58.6'' (1.49m) |
| Basic (2 pairs)*1+add on kit (2 pairs)*2 | 90'' (2.3m) | 84.6'' (2.15m) |
| Basic (2 pairs)*1+add on kit (2 pairs)*3 | 118'' (3m) | 112.2'' (2.85m) |
Soft Material
Without Conveyor Rail, the material can be hung down on both sides of the working area of conveyor feeder.（Some soft materials need to be processed with PET tape）
Customer Reviews
I was making a national parks style wedding sign for a client and I had designed it to fit into my S1 without any accessory. Suddenly, the customer asked for the sign to be larger and those dimensions made it not fit into my S1. Yikes! What was I supposed to do. Fortunately, when I ordered the S1 it was a bundle that included this conveyor system. I was nervous because I had never used it and I was now on a tight deadline to get the sign done. I set it up, adjusted the design for the larger size and only did one test run for the larger part of the sign. Worked perfectly. I then ran all of the parts of the sign using both 1/4" and 1/2" birch plywood and they came out beautifully. It was so cool to see it move the wood in and out of the S1.
Warning note: you do have to make sure you have enough wood on the conveyor that is much larger than your design so that the rollers can move the wood. CHECK THE USER MANUAL for this and you will not have any issues.
Great accessory that I highly recommend. See picture of the final sign.
I like that I have the option to cut wood wider that 12 inches. I have used the convayor to cut larger wreaths and also made an advent calendar.
If apple made a laser machine, this is how it would turn out. Sleek, beautiful, productive, easy to use, with endless possibilities. The conveyor system opens up new lengths in imagination. I have used many lasers, and this is what a premium laser is.
Love my conveyor! Levels up my crafting game, definitely excited to see what all I can accomplish with this in my toolbox
I’ve only had to use the conveyor a few times but it has been very handy every time that I have had to. There is a little bit of a learning curve for sure but once you get past that it’s fantastic
